SMART WALL SWITCH

Capacitive Glass Multi-Key Interface Nodes

System Overview

An architectural-grade control terminal engineered to bridge tactical physical contact with wireless network automation. Replaces cumbersome legacy toggle plates with an ultra-responsive touch configuration. Designed with an elegant LED background luminescent guide for instant nighttime location lookups, it offers zero-friction manual interaction alongside continuous remote cloud dashboard override capabilities.

Key Operational Features

  • Premium manual touch layout integrated with high-sensitivity capacitive panel tracking logic.
  • High-quality tempered glass plate coupled with structural PC fire-retardant internals testing up to a 100,000-cycle operational service life.
  • Simplified easy installation pathways engineered to bypass cumbersome traditional rewiring hurdles completely.
SMART WALL SWITCH System Visualization
Hardware Telemetry Matrix
Model Configuration DMS - DH01 / 02 / 03 / 04
Operating Voltage AC 85V - 265V / 50-60Hz
Maximum Load Power 200W Matrix Cap
Switch Hardware Type Null & Live Wire / Live Only
Chassis Material Brushed Metal + Tempered Glass
Orientation Accent LED Luminescent Background Guide
Wireless Radio Profile 2.4G Zigbee 802.15.4 Mesh
Environmental Tolerances -40°C ~ +85°C (<=95% RH)
